Thông số kỹ thuật
| Power-handling nominal (RMS) | 400 W |
| Power-handling, program | 800 W |
| Power-handling, peak | 1200 W |
| Nominal impedance | 8 ohms |
| Max SPL | 128 dB half space (@10% THD) |
| Sensitivity 1W/1m | 104 dB half space |
| Frequency response +/- 3 dB | 60 Hz – 20 kHz |
| Frequency response -10 dB | 53 Hz – 20 kHz |
| Low/Mid Speaker | 1x 15" |
| HF Driver | 1" |
| HF horn | 60° x 40° CD horn |
| HF protection (passive) | Dyn. protective circuit |
| Crossover frequency | 2.2 kHz, 12 dB/oct. |
| Connections | 2x Speakon NL4 |
| Pole mount | DuoTilt 3/7 |
| Rigging points | 3x M8 |
| Handles | 2, integrated |
| Grille | Metal grille with black acoustic foam |
| Finish | Acrylic enamel, black |
| Optional accessories | Protective cover, Satellite Add-On M20, Adjustable pole M20 |
| Dimensions (WxHxD) | 47 x 62.5 x 43 cm |
| Weight | 22.6 kg / 49.8 lbs |
