Thông số kỹ thuật
| Power-handling nominal (RMS) | 500 W |
| Power-handling, program | 1000 W |
| Power-handling, peak | 1500 W |
| Nominal impedance | 4 ohms |
| Max SPL | 128 dB half space (@10% THD) |
| Sensitivity 1W/1m | 104 dB half space |
| Frequency response +/- 3 dB | 48 Hz – X-over |
| Frequency response -10 dB | 38 Hz – X-over |
| LF Speaker | 1x 18" |
| Crossover frequency | 150 Hz, 12 dB/oct. |
| Connections | 2x Speakon NL4 |
| Pole mount | 1x M20 |
| Handles | 2, integrated |
| Casters | optional 100 mm |
| Enclosure | MDF |
| Grille | Metal grille with black acoustic foam |
| Finish | Acrylic enamel, black |
| Optional accessories | Protective cover, Satellite Add-On M20, Adjustable pole M20 |
| Dimensions (WxHxD) | 53 x 61 x 64 cm |
| Weight | 39.8 kg / 87.7 lbs |
