Thông số kỹ thuật
Power-handling nominal (RMS)300 W
Power-handling, program600 W
Power-handling, peak1200 W
Nominal impedance8 ohms
Max SPL126 dB half space (@10% THD)
Sensitivity 1W/1m99 dB half space
Frequency response +/- 3 dB95 Hz - 19 kHz
Frequency response -10 dB80 Hz - 19 kHz
Low/Mid Speaker1x 10"
HF Driver1"
HF horn90° x 60° CD horn
HF protection (passive)Dyn. protective circuit
Crossover frequency2.2 kHz, 12 dB/oct.
Connections2x Speakon
NL4Angles up35°
Pole mountDuoTilt 3/7
Rigging points3x M8
Handles1, integrated
EnclosureMDF
GrilleMetal grille with black acoustic foam
FinishAcrylic enamel, black
Optional accessories
Protective cover, Satellite Add-On M20,
Adjustable pole M20Dimensions (WxHxD)32 x 48.5 x 30 cm
Weight12.5 kg / 2.6 lbs
